[Alfagomma] Water discharge 10 bar (150 psi) - Lay flat
[Alfagomma] Water discharge 10 bar (150 psi) - Lay flat
Couldn't load pickup availability
Water discharge 10 bar (150 psi) - Lay flat
Tube: black EPDM.
Reinforcement: high tensile textile cords.
Cover: black EPDM - abrasion and ozone resistant.
Application: lay flat water discharge.
Constant operation: -30 °C +80 °C (-22 °F +176 °F)
| Internal Diameter | Internal Diameter | Outside Diameter | Outside Diameter | Maximum Working Pressure | Maximum Working Pressure | Minimum Burst Pressure | Minimum Burst Pressure | Minimum Bend Radius | Minimum Bend Radius | Vacuum | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | bar | psi | bar | psi | mm | in | % | kg/m | lb/ft |
| 32,0 | 1 1/4" | 40,0 | 1,57 | 10 | 150 | 30 | 450 | – | – | – | 0,460 | 0,31 |
| 38,0 | 1 1/2" | 46,0 | 1,81 | 10 | 150 | 30 | 450 | – | – | – | 0,540 | 0,37 |
| 40,0 | 1 9/16" | 48,0 | 1,89 | 10 | 150 | 30 | 450 | – | – | – | 0,570 | 0,39 |
| 45,0 | 1 3/4" | 53,0 | 2,09 | 10 | 150 | 30 | 450 | – | – | – | 0,660 | 0,45 |
| 51,0 | 2" | 59,0 | 2,32 | 10 | 150 | 30 | 450 | – | – | – | 0,730 | 0,50 |
| 60,0 | 2 3/8" | 68,0 | 2,68 | 10 | 150 | 30 | 450 | – | – | – | 0,860 | 0,58 |
| 63,0 | 2 1/2" | 71,0 | 2,80 | 10 | 150 | 30 | 450 | – | – | – | 0,900 | 0,61 |
| 70,0 | 2 3/4" | 80,0 | 3,15 | 10 | 150 | 30 | 450 | – | – | – | 1,380 | 0,93 |
| 76,0 | 3" | 86,0 | 3,39 | 10 | 150 | 30 | 450 | – | – | – | 1,480 | 1,00 |
| 90,0 | 3 1/2" | 100,0 | 3,94 | 10 | 150 | 30 | 450 | – | – | – | 1,720 | 1,16 |
| 102,0 | 4" | 112,0 | 4,41 | 10 | 150 | 30 | 450 | – | – | – | 2,040 | 1,38 |
| 127,0 | 5" | 139,0 | 5,47 | 10 | 150 | 30 | 450 | – | – | – | 2,730 | 1,84 |
| 152,0 | 6" | 164,0 | 6,46 | 10 | 150 | 30 | 450 | – | – | – | 3,360 | 2,26 |
| 168,0 | 6 5/8" | 180,0 | 7,09 | 10 | 150 | 30 | 450 | – | – | – | 3,560 | 2,40 |
| 203,0 | 8" | 217,0 | 8,54 | 10 | 150 | 20 | 300 | – | – | – | 4,810 | 3,24 |
| 254,0 | 10" | 270,0 | 10,63 | 10 | 150 | 20 | 300 | – | – | – | 7,680 | 5,17 |
| 305,0 | 12" | 319,0 | 12,56 | 10 | 150 | 20 | 300 | – | – | – | 8,870 | 5,97 |
